Product description
Is a intelligence flux showing meter, it can be matched with any
flow meter produced by our company；
It has the advantage of simply use, high accuracy degree,
stable character, high resistance of interference,
showing directly etc.
Product features
1.There are three lines liquid crystal screen to show the accumulation
flux, instant flux,differentialpressure, frequency,density,pressure,
temperature, present time and the power on and off inquiry.
2.Temperature and pressure can be compensated automatically,
it also has the ability of density function and several flux operation
model；Function of cutting off power for protection, can memory the date for long time.
3.Renovation automatically, software and hardware both have watchdog.
Technical parameters
1.Flux signal input: 0~5000Hz(V low≤1V,V high≥5V)、0~10mA、4~20mA; Pressure signal input:0~10mA、4~20mA;
2.Temperature signal input: 0~10mA、4~20mA or PT100；Signal output:4~20mA;
3.measurement accuracy degree: analog quantity superior 0.2%, frequency superior 0.1%;
4.Performance work source: AC220V 15%; environmental temperature: 30~+55℃, environmental moistness:5~95%RH;overal size:160*80*150(wide*high*deep,unit: mm);Opening*76(wide*high,unit: mm)Size:
